Composite board
Coated metal composite board
Laminated Composite Aluminum Panel (Architecture & Decoration)** A pre-finished aluminum panel with a polymer film (PVC/PVDF) bonded to its surface. It offers: – **Material**: Aluminum core (0.5–3.0mm) + protective/decorative film. – **Key Features**: Lightweight, weatherproof (PVDF for outdoors), scratch-resistant, and customizable (colors/patterns). – **Uses**: Curtain walls, ceilings, partitions, cladding. – **Types**: Standard (indoor PVC), high-end (outdoor PVDF), fireproof, antibacterial. – **Benefits**: Easier installation & maintenance vs. painted metal/stone. Choose film type (PVC/PVDF) and thickness based on indoor/outdoor needs.
Related products
Aluminum extruded ceiling
◎Product Features
In modern buildings, aluminum extrusion design has become a trend as curtain walls, interior ceilings and walls of buildings. Therefore, customers have higher requirements for the quality and shape of aluminum extrusion ceilings and walls. Our company can customize the design and production according to the needs of the above uses to meet the needs of customers.
Customization: production in accordance with demand, the price is very competitive.
Diversified colors: a variety of wood grain colors, to meet the needs of the project at one time.
Easy to assemble and disassemble: systematized skeleton, assembly and disassembly are done at one time.
Multiple combinations: many specifications and styles, can be matched in a variety of ways.
Less gap connection: the length is more than 6 meters, reducing the connection gap.
Good appearance of the cover: the cover design is mostly [one-piece molding] snap-on.
◎Surface treatment
Powder high weather-resistant paint, fluorocarbon paint, wood grain vacuum thermal transfer.
◎Applicable occasions
Station, commercial office building, arcade, balcony, parking lot, office...etc.
Aluminum honeycomb
Modern design mainly pursues a simple and elegant style, so it is necessary to reduce the seams of the panels, so large-sized panels have become the mainstream of design.
Large-sized panels need to use the hexagonal geometric structure of the honeycomb to achieve the best panel strength and flatness under the conditions of lightness and economy.
Microporous sound absorbing board vertical baffle
Microporous sound-absorbing board baffle series, Microporous sound absorbing board vertical baffle, Ultra-micro sound-absorbing series, All Products
The vertical baffle system divides the space into several small spaces with vertical panels, which can cut the sound source into segments. It is better than other series of products in reducing echo and resonance; it is especially suitable for large spaces with many people and noise. The array arrangement of the products makes the space have an infinite extension effect. It is visually beautiful and generous. Because it does not need to be covered with sound-absorbing cotton, its durability can reach more than 10 years, and there is no risk of sinking due to moisture. It is environmentally friendly, recyclable and highly sound-absorbing.
Outdoor soundproof wall
Ultra-micro sound-absorbing series, Microporous sound-absorbing board sound-absorbing wall series, Outdoor soundproof wall, All Products
Traditional sound-absorbing soundproof walls are exposed to the natural environment, wind, sun and rain. The inner layer of sound-absorbing cotton will sink after absorbing water, affecting the sound absorption and insulation effect, leaving only about 3~5 decibels of volume reduction. The life of traditional soundproof walls is about 1~3 years. And it is impossible to maintain and clean it. In the end, it can only be dismantled and replaced, which requires more construction costs and leads to greater losses.
In the harsh outdoor environment, SoundMicro microporous sound-absorbing panels have the advantages of high sound absorption (NRC 0.85 or above), high sound insulation (STC 32dB or above), light weight, waterproof, dustproof and acid and alkali resistance... and can be cleaned and maintained by rain or high-pressure water jets, with a service life of more than 10 years.
Paper Honeycomb
Paper Honeycomb
Modern design mainly pursues a simple and elegant style, so it is necessary to reduce the joints of the panels, so large-sized panels have become the mainstream of design.
Large-sized panels need to use the hexagonal geometric structure of the honeycomb to achieve the best panel strength and flatness under the conditions of lightness and economy.
Perforated aluminum veneer
The perforated aluminum veneer uses high-quality 1100, 3003, 5005 single-layer aluminum alloy plate as the base material. The surface coating is divided into fluorocarbon spraying, powder spraying, polyester paint spraying, and fluorocarbon pre-roller coating. From top to bottom: protective film layer, fluorocarbon resin PVDF system, pretreatment layer, aluminum plate layer, pretreatment layer, back coating.
Zinc titanium sheet
SilesiaZINC zinc-titanium sheet is manufactured in accordance with the PN-EN 988 standard and is available in three variants, differing only in the finish of the outer surface:
NATURAL – features a metallic, shiny surface that gradually develops a light grey matte patina over time due to exposure to atmospheric conditions.
PRE-AGED GREY – features a matte, light grey surface with a patina created through a controlled chemical process. To avoid the transitional phase of natural patina formation, factory-patinated sheets are recommended for exposed architectural elements such as façades.
PRE-AGED CARBON – a new type of patina with a shade close to graphite black, created through a complex technological process. This material contrasts beautifully with lighter colors, giving buildings a unique and distinctive character. It pairs perfectly with other materials, such as natural slate.
